Financial Data Center Environment Management Solution
Server room features:
● Server room with an area of more than 500 m2
● Single frame load is about 5kW
● High heat density rack area with single rack load greater than 5kW
● 365 × 24x7 operation
● Indoor requirements: temperature 23 ℃± 2, humidity 50% ± 5, cleanliness ≥ 0.5 μ ≤ 18000 grains/l
Main requirements:
● Maintainability: low maintenance cost, low professional requirements and low maintenance difficulty.
● Reliability: at least 99.999%, the system has no single point of failure, and the failure problem can be removed within 10 minutes or there is a backup scheme for switching.
● Energy saving: high energy efficiency equipment shall be used, and the system energy saving design, operation energy saving and design energy saving shall be considered.
● Economy: the overall investment is cost-effective, and the cost of capital can be reduced by investing in batches.
Recommended solution:
● The main demand characteristics of the financial data center are: the conventional load area of the large and medium-sized data center with reliability first, followed by economy and energy conservation greater than 500 ㎡. It is recommended to use FPM medium and large machine room air conditioning series water-cooled type, double cooling source type, chilled water double coil type or single coil type unit; In the high heat density load area, it is recommended to use FPR in row room dedicated air conditioning series water-cooled or chilled water units; In the modular data center area, it is recommended to use the regular load area of small and medium-sized data centers where the dedicated air conditioning series chilled water type units for FPR inter column machine rooms are less than 500 ㎡, and it is recommended to use the air cooling type units or double cooling source type units for FPM large and medium-sized machine rooms; In high heat density load area or modular data center area, it is recommended to use FPR in row room dedicated air conditioning series air-cooled units; In low temperature north area, FPF fluorine pump natural cooling machine room dedicated air conditioning series energy-saving air cooling units or natural cooling energy-saving units are recommended for conventional load areas.
|
● Reliability: at least 99.999%, the system has no single point of failure, and the failure problem can be removed within 10 minutes or there is a backup scheme for switching. |
